Photometer dan Colorimeter

PORTABLE COLORIMETER

Model  : C-101 ( pH)

Fungsi : Alat pengukur kadar pH dalam air, layar yang lebar, pengukuran mudah dan praktis serta anti air.

Spesifikasi :
* Measurement Method : Photometric
* Light Source : Light Emitting Diode ( LED)
* Wavelength : 525nm
* Detector : Silicon photodiode
* Absorbance Range : 0 - 2.5 Abs
* Photometric Precision : ± 0.0015Abs
* Automatic Range Selection : 5.9 - 8.2 pH
* Resolution : 0.1 pH ( 5.9 - 8.2 pH)
* Accuracy : ± 0.1 pH ( 5.9 – 8.2 pH)
* Calibration Points : User selectable; 1 point per colorimetric test
* Display : 4-digit 14-segments customized liquid crystal display with annunciators
* Sample Cells : Borosilicate glass with screw caps, fill line and indexing mark Height x Diameter : 51 x 25 mm
* Sample Volume Required : 10 ml
* Operating Temperature Range : 0 – 50° C
* Operating Humidity Range : 0-90% RH non-condensing at 30° C
* Power Supply : 4 ‘ AAA’ alkaline batteries
* Battery Life : > 3000 tests
* Electromagnetic : EN 61326 Compliance ( EMC)
* Weight Instrument : 200g
* Complete carrying case : 1.25kg
* Dimensions Instrument : 6.8( W) x 15.5( L) x 4.6( H) cm
* Carrying case : 16( W) x 35( L) x 12( H) cm





PORTABLE COLORIMETER

Model  : C-102 ( Cyanuric Acid)


Fungsi : Alat pengukur kadar Cyanuric Acid dalam air, layar yang lebar, pengukuran mudah dan praktis serta anti air.

Spesifikasi :
* Measurement Method : Photometric
* Light Source : Light Emitting Diode ( LED)
* Wavelength : 525nm
* Detector : Silicon photodiode
* Absorbance Range : 0 - 2.5 Abs
* Photometric Precision : ± 0.0015Abs
* Automatic Range Selection : 5 - 90 ppm Cyanuric Acid
* Resolution : 1 ppm Cyanuric Acid
* Accuracy : ± 4 ppm Cyanuric Acid
* Calibration Points : User selectable; 1 point per colorimetric test
* Display : 4-digit 14-segments customized liquid crystal display with annunciators
* Sample Cells : Borosilicate glass with screw caps, fill line and indexing mark Height x Diameter : 51 x 25 mm
* Sample Volume Required : 10 ml
* Operating Temperature Range : 0 – 50° C
* Operating Humidity Range : 0-90% RH non-condensing at 30° C
* Power Supply : 4 ‘ AAA’ alkaline batteries
* Battery Life : > 3000 tests
* Electromagnetic : EN 61326 Compliance ( EMC)
* Weight Instrument : 200g
* Complete carrying case : 1.25kg
* Dimensions Instrument : 6.8( W) x 15.5( L) x 4.6( H) cm
* Carrying case : 16( W) x 35( L) x 12( H) cm





PORTABLE COLORIMETER

Model : C-103 ( Chlorine Dioxide)


Fungsi : Alat pengukur kadar Chlorine Dioxide dalam air, layar yang lebar, pengukuran mudah dan praktis serta anti air.
Spesifikasi :
* Measurement Method : Photometric
* Light Source : Light Emitting Diode ( LED)
* Wavelength : 525nm
* Detector : Silicon photodiode
* Absorbance Range : 0 - 2.5 Abs
* Photometric Precision : ± 0.0015Abs
* Automatic Range Selection : 0 to 3.79 ppm; 3.8 to 11.4 ppm
* Resolution : 0.01 ppm; 0.1 ppm
* Accuracy : ± 0.02 ppm; ± 0.2 ppm
* Calibration Points : User selectable; 1 point per colorimetric test
* Display : 4-digit 14-segments customized liquid crystal display with annunciators
* Sample Cells : Borosilicate glass with screw caps, fill line and indexing mark Height x Diameter : 51 x 25 mm
* Sample Volume Required : 10 ml
* Operating Temperature Range : 0 – 50° C
* Operating Humidity Range : 0-90% RH non-condensing at 30° C
* Power Supply : 4 ‘ AAA’ alkaline batteries
* Battery Life : > 3000 tests
* Electromagnetic : EN 61326 Compliance ( EMC)
* Weight Instrument : 200g
* Complete carrying case : 1.25kg
* Dimensions Instrument : 6.8( W) x 15.5( L) x 4.6( H) cm
* Carrying case : 16( W) x 35( L) x 12( H) cm





Portable Colorimeter

Model : C-105 ( Ozone)


Fungsi : Alat pengukur kadar Ozone dalam air, layar yang lebar, pengukuran mudah dan praktis serta anti air.

Spesifikasi :
* Measurement Method : Photometric
* Light Source : Light Emitting Diode ( LED)
* Wavelength : 525nm
* Detector : Silicon photodiode
* Absorbance Range : 0 - 2.5 Abs
* Photometric Precision : ± 0.0015Abs
* Automatic Range Selection : 0 to 1.39 ppm; 1.4 to 4.1 ppm
* Resolution : 0.01 ppm; 0.1 ppm
* Accuracy : ± 0.02 ppm; ± 0.2 ppm
* Calibration Points : User selectable; 1 point per colorimetric test
* Display : 4-digit 14-segments customized liquid crystal display with annunciators
* Sample Cells : Borosilicate glass with screw caps, fill line and indexing mark Height x Diameter : 51 x 25 mm
* Sample Volume Required : 10 ml
* Operating Temperature Range : 0 – 50° C
* Operating Humidity Range : 0-90% RH non-condensing at 30° C
* Power Supply : 4 ‘ AAA’ alkaline batteries
* Battery Life : > 3000 tests
* Electromagnetic : EN 61326 Compliance ( EMC)
* Weight Instrument : 200g
* Complete carrying case : 1.25kg
* Dimensions Instrument : 6.8( W) x 15.5( L) x 4.6( H) cm
* Carrying case : 16( W) x 35( L) x 12( H) cm





PORTABLE COLORIMETER
Model : C-401

Fungsi : Alat pengukur kadar Free & Total Chlorine, Cyanuric Acid, pH dalam air, layar yang lebar, pengukuran mudah dan praktis serta anti air.

Spesifikasi :
* Chlorine, Free and Total : 0 to 1.99 ppm; 0.01 ppm; ± 0.02 ppm; 2.0 to 6.0 ppm; 0.1 ppm; ± 0.2 ppm
* Cyanuric Acid : 5 to 90 ppm; 1 ppm; ± 4 ppm
* pH : 5.9 to 8.2 pH; 0.1 pH; ± 0.1 pH
* Measurement Method : Photometric
* Light Source : Light Emitting Diode ( LED)
* Wavelength : 525nm
* Detector : Silicon photodiode
* Absorbance Range : 0 - 2.5 Abs
* Photometric Precision : ± 0.0015Abs
* Automatic Range Selection : 0 - 1.99 ppm ( Free & Total Chlorine) ; 2.0 - 6.0 ppm ( Free & Total Chlorine) ; 5 - 90 ppm ( Cyanuric Acid) ; 5.9 - 8.2 pH
* Resolution : 0.01 ppm ( 0 - 1.99 ppm; Free & Total Chlorine) ; 0.1 ppm ( 2.0 - 6.0 ppm; Free & Total Chlorine) ; 0.1 pH ( 5.9 - 8.2 pH) ; 1 ppm ( 5 - 90 ppm; Cyanuric Acid)
* Accuracy : ± 0.02 ppm ( 0 – 1.99 ppm; Free & Total Chlorine) ; ± 0.2 ppm ( 2.0 – 6.0 ppm; Free & Total Chlorine) ; ± 0.1 pH ( 5.9 – 8.2 pH) ; ± 4 ppm; Cyanuric Acid
* Calibration Points : User selectable; 1 point per colorimetric test
* Display : 4-digit 14-segments customized liquid crystal display with annunciators
* Sample Cells : Borosilicate glass with screw caps, fill line and indexing mark Height x Diameter : 51 x 25 mm
* Sample Volume Required : 10 ml
* Operating Temperature Range : 0 – 50° C
* Operating Humidity Range : 0-90% RH non-condensing at 30° C
* Power Supply : 4 ‘ AAA’ alkaline batteries
* Battery Life : > 3000 tests
* Electromagnetic : EN 61326 Compliance ( EMC)
* Weight Instrument : 200g
* Complete carrying case : 1.25kg
* Dimensions Instrument : 6.8( W) x 15.5( L) x 4.6( H) cm
* Carrying case : 16( W) x 35( L) x 12( H) cm





Amonia Meter
The new Palintest Ammonia Meter is a precision dual range Photometer for measuring Ammonia concentration in water. The single parameter meter is used in conjunction with the Tubetests Nessler reagent. The system provides a quick and simple but accurate way to monitor ammonia levels.

• Tests for Ammonia 0.06 - 15 mg/ l, N, 0.5 - 50 mg/ l N, 1 - 100 mg/ l N
• Robust, Waterproof, IP 67 Rating
• Available in hard or soft carry case
• Easy to use ( 4 intuitive buttons)
• Ideal for routine water monitoring

Instrument Type : Dual wavelength, direct-reading colourimeter
Optics : Palintest dual LED light source optical system with narrow band wavelength filters and
photodetectors

Wavelengths : 430 nm
Wavelength Tolerance : ± 2nm
Filter Bandwidth 10nm : LCD Display 128 x 64 pixel screen
Instrument Operating Temperature Range : 0 to 50° C
Test Cells : 16 mm diameter tubes
Blank/ Zero setting : Held in memory or reset for each reading
Power Supply : 2 x 1.5V ‘ AA’ batteries. Auto switch-off setting
Size : 150 x 65 x 40 mm
Weight : 200g



PORTABLE COLORIMETER



 Model : C-401

Fungsi : Alat pengukur kadar Bromine dalam air, layar yang lebar, pengukuran mudah dan praktis serta anti air.

Spesifikasi :
* Measurement Method : Photometric
* Light Source : Light Emitting Diode ( LED)
* Wavelength : 525nm
* Detector : Silicon photodiode
* Absorbance Range : 0 - 2.5 Abs
* Photometric Precision : ± 0.0015Abs
* Automatic Range Selection : 0 to 4.49 ppm; 4.5 to 13.5 ppm
* Resolution : 0.02 ppm; 0.2 ppm
* Accuracy : ± 0.03 ppm; ± 0.3 ppm
* Calibration Points : User selectable; 1 point per colorimetric test
* Display : 4-digit 14-segments customized liquid crystal display with annunciators
* Sample Cells : Borosilicate glass with screw caps, fill line and indexing mark Height x Diameter : 51 x 25 mm
* Sample Volume Required : 10 ml
* Operating Temperature Range : 0 – 50° C
* Operating Humidity Range : 0-90% RH non-condensing at 30° C
* Power Supply : 4 ‘ AAA’ alkaline batteries
* Battery Life : > 3000 tests
* Electromagnetic : EN 61326 Compliance ( EMC)
* Weight Instrument : 200g
* Complete carrying case : 1.25kg
* Dimensions Instrument : 6.8( W) x 15.5( L) x 4.6( H) cm
* Carrying case : 16( W) x 35( L) x 12( H) cm






Spectrophotometer
Model : Photolab S12

Filter photometer with 12 wavelengths for an extensive routine operation in service laboratories and for education. Besides the barcoded reaction test kits, there is also a considerable number of reasonable reagent test kits available for rectangular cuvettes. Uniquely, the barcode support also comes with the test kits for 10 mm, 20 mm and 50 mm rectangular cuvettes. Especially within the drinking water analysis even trace concentrations are covered.

The instrument is therefore highly efficient and cost-saving for:
• routine determinations with a large number of samples
• measuring of smallest concentrations
• special tasks with user-defined methods

The additional characteristic for own routine and kinetics measurements make this instrument suitable for servicing business units and education. The photoLab® filter photometers offer laboratory precision in combination with highest comfort and fastest measuring speed. This becomes especially valuable in routine operation:

Speed and accuracy originate from the used filter technology with reference beam technique. Combined with barcoded round and rectangular cuvette tests utmost efficient and cost-saving measuring is made possible for all demands. The given wavelengths by high-precision filters do not require any mechanics and therefore make this measuring instrument practically a maintenance free unit.

• Auto Check for highest stability and precision
• Automatic cuvette recognition for all used cuvette types
• Automatic test recognition through integrated barcode reader
• Automatic measuring start
• Automatic Quality Assurance AQA
• Broad selection of programmed test kits


 Untuk Informasi Harga Silahkan Hubungi Kami
